무제 문서     Chip Fabrication

2023.10 2024.02

2023_Yonsei_HSCS [AMF SOI]

MRM/MRR Farm, 4-ch Tx, 4-ch Rx, Weight bank, Ring PD, RAMZI, PDK cells


2023.07 2024.01

S2307 [samsung 28nm Logic RF CMOS]

APD Orx with HGMON, 1-CH MRM Tx with controller


2023.04 2023.07

M13716 [TSMC 180nm MS RF G]

32ch OPA Phase shifter driver IC


2023.01 ~ 2023.07

S2301 [samsung 28nm Logic RF CMOS]

APD Rx, 56G PAM4 Receiver with 4 tap FFE, 1 tap DFE


2022.10 ~ 2023.03

S2210 [samsung 28nm Logic RF CMOS]

56G PAM4 Recevier with 4 tap FFE, 1 tap DFE, 56G PAM4 Optical Transmitter, POS, APD


2022.07 ~ 2022.12

S2207 [samsung 28nm Logic RF CMOS]

APD Farm , High-speed TX with T-Coil


2022.04 2022.08

Yonsei_2022 [AMF SOI]

Si Mach-Zehnder Modulators, 28G PDs, BPDs, Si Ring Modulators


2022.04 ~ 2022.10

S2204 [samsung 28nm Logic RF CMOS]

Transmitter, Receiver Front End , 4-ch WDM Rx, Test block


2021.10 2022.04

S2110 [samsung 28nm Logic RF CMOS]

TIA, CDR, TX, PLL


2021.08 TBD

YONSEI_2021 [imec iSiPP50G]

RAMZI for QPSK, 2RAMZI for push-pull QPSK, Coupling modulation, Active MMI


2021.04 2021.10

S2104 [Samsung 28nm RF CMOS]

PAM-4 Tx, PAM-4 CDR, AFE with EOM, Optical Switch Controller


2021.04 2021.07

202104_NanoSOI [NanoSOI PIC]

4 x 4 MZI based optical switch matrix, Stacked dual ring phase modulators, RAMZIs


2020.10 2022.02

YONSEI_2020 [imec iSiPP50G]

Dual RMs for QPSK, Single RMs for BPSK, Heater crosstalk blocks


2020.09 2021.03

S2009 [Samsung 28nm CMOS]

Tx with FFE, ORx with PDE


2020.05 2021.12

T448 [IHP SG25H5_ePIC_Cu_BEOL]

Dual-ring QPSK Modulator, 2/4 channel WDM Ring Filter Array with PD, SF-TIA Optical Receivers, BiCMOS PRBS Generator, Heater Optimization Test Blocks


2020.03 2020.09

S2003 [Samsung 28nm CMOS]

WDM Filter Controller, NRZ CDR, LC VCO, PAM-4 Tx


2019.10 2020.04

S1910 [Samsung 28nm CMOS]

PAM4 Tx, Optical Rx, Test Inductor


2019.05 2019.11

S1905 [Samsung 28nm CMOS]

PRBS Generator, 2ch WDM Rx, 25G ORx


2019.02 2020.08

0_YONEPIC_1902 [IHP SG25H5_ePIC]

C-band 2-ch WDM Tx


2018.12 2019.04

S1812 [Samsung 28nm CMOS]

Optical Tx, Optical Rx


2018.10 2019.10

0_KETI2018V2 [IHP SG25H4_ePIC]

1550-nm Coherent EPIC Rx, 1310-nm PSM4 EPIC Rx
Si RM farm for Stressor Nitride RMs, 4 x 4 MMI


2018.06 2018.10

S1806 [Samsung 28nm CMOS]

PAM4 Tx, Optical Rx


2018.04 2019.05

0_KETI_2018A [IHP SG25H4_ePIC]

1310nm Si RM, 4-Ch WDM Rx, 1-Ch Rx, 1-Ch Tx


2018.04 2019.05

0_YONEPIC_2018A [IHP SG25H4_ePIC]

1310nm Si RM, 1-Ch Rx, 1550-nm 2-Ch PAM4 Tx, Comb Generator, Si Ring QPSK Modulator, 1-Ch Driver


2017.10 2018.08

0_YS_2017 [IHP SG25H4_ePIC]

4-Ch WDM EPIC Tx w/ PAM4, 1-Ch WDM EPIC Rx, QPSK EPIC Tx


2017.08 2017.11

Leo2017 [Samsung 28nm CMOS]

PAM4 Tx, sampler, 25G ORx


2017.04 2018.01

0_IHPPIC [IHP SG25PIC]

1310 nm WDM Tx(4Ch, 2Ch), 1310 nm WDM Rx(4Ch, 2Ch) BPSK, QPSK TRx, Si MRM


2017.02 2017.06

Picses2017 [Samsung 28nm CMOS]

4-ch Tx, PAM4 Tx


2016.11 2018.03

0_YONSEI_PIC [IHP SG25H4_ePIC]

ADMRMs, Ring Filters, 2,4-ch WDM TRx, Heaters


2016.11 2018.03

0_YONSEI_EPIC [IHP SG25H4_ePIC]

4-ch WDM Tx with controller, 2-ch WDM Rx, ADMRMs, Ring Filters


2016.08 2016.11

Leo2016 [Samsung 28nm CMOS]

4-channel TX, 4PAM TRx


2016.04 2016.08

Pisces2016 [Samsung 28nm CMOS]

toggle TRX, MRM controller, 25G ORX/TX


2015.10 2016.08

0_YNSEI [IHPSG25PIC]

Optical filter, MRM and heater for WDM


2015.10 2016.08

0_MIN_YONSEI [IHP SG25H1]

1-ch WDM Rx, 2-ch WDM Tx, Controller test block


2015.01 2016.07

0_Capricorn2015 [IHP SG25 EPIC]

High-Speed Opto-electronics Transceiver


2014.10 2015.04

Scorpio2015 [IHP SG25H1]

MZM bias controller with CMOS APD


2014.10 2014.12

Dongbu_011_min [Dongbu 0.11um CIS (CMOS Image Sensor)]

High-speed CIS avalanche photodiode design


2014.08 2015.06

YONSEI_IHP_PIC [IHP SG25_PIC]

Ring Modulator


2014.08 2015.03

Virgo2014 [IDEC MPW S1402, samsung 65nm Logic CMOS]

Transceiver (Low power Serializer, SerDes, CDR)


2014.01

Capricorn2013 [TSMC 65nm CMOS General Purpose]

25Gb/s Opto-electonic Transceiver


2013.12 2014.06

Sagittarius2013 [IDEC MPW126, samsung 65nm Logic CMOS]

20Gb/s CDR and TIA, PLL


2013.07

Thecrab2013 [IDEC MPW121, samsung 65nm Logic CMOS]

12.5Gb/s EPIC ORx, ULV PLL, Tx


2013.05

Taurus2013 [Magna 0.18um CMOS]

.


2013.03

OpSIS_YU_201302 [OpSIS-IME-002, SOI]

25 Gbps optical device design (Photodetector, Ring modulator, SSB, passive)


2013.03

OpSIS_YU_201302_Passive [[OpSIS-IME-002, SOI]]

25 Gbps optical device design only passive structure (Photodetector, Ring modulator, SSB, passive)


2013.03

OpSIS_YU_201302_Active [OpSIS-IME-002, SOI]

25 Gbps optical device design (Photodetector, Ring modulator, SSB, passive)


2013.02

YSCKC [TSMC 0.18um]

ADPLL and CDR


2012.12

Sagittarius2012 [IDEC MPW117, samsung 65nm Logic CMOS]

20Gb/s Tx and Rx, DCC, PLL


2012.10 2013.08

OpSIS_YU_201310 [OpSIS-IME004]

25Gb/s Optical Si-MRM, K-modulator, KETI


2012.08

Virgo2012 [Samsung 130nm CMOS]

Ultra-Low Voltage PLL and TDC


2012.06.

Gemini2012 [IDEC MPW112, Samsung 65nm CMOS Logic]

20Gbps Optical Transceiver


2012.04

Aries2012 [TSMC 65nm CMOS General Purpose]

20Gb/s Opto-electronic Transceiver


2012.03.

Pisces2012 [IDEC MPW109, Samsung 130nm CMOS Logic]

PVT-compensated All-Digital Phase-Locked Loop


2011.06.

Leo2011 [IDEC MPW104, Samsung 65nm CMOS Logic]

10Gbps Full Transceiver


2011.05

Pororo [IDEC TSMC 180nm]

5-GHz Power Amp


2011.04

HSCS YU [IHP 250nm]

60-GHz Miller Divder & Integrated Miller divider and Copitts VCO, CMOS-APD, Optical Receiver, 60-GHz Optical-to-Wireless Converter, DC-DC Boost Converter


2011.04

Taurus WS EQ [IDEC MPW100, samsung 90nm]

A 6Gb/s Adaptive Preemphasis Using Asynchronous-Sampling Histograms


2010.5

Hyunah [IHP 250nm]

Antipodal APD Mixer, CMOS-APD, VCO, LNA, Mixer, Receiver, Optical Receiver


2010.08

Pooh [IDEC MPW95, TowerJazz 180nm]

60-GHz Colpitts VCO


2010.06

Miracle [TSMC 180nm]

Ku-band LNA


2010.03

Arthas [IDEC MPW91, samsung 130nm]

Digital Controlled Oscillator


2009. 07

Bigbang WS EQ [IDEC MPW90, samsung 130nm]

A 5.4Gb/s Adaptive Equalizer Using Asynchronous-Sampling Histograms
